Philosophy

Stop overcomplicating sounds, let's keep it simple:

Erika.new():Play( SOUND_ID_HERE )

Better yet, let's add a visualizer too:

Erika.new():Play( SOUND_ID_HERE ):CreateVisualizer2D( GuiObject , {
	BarCount = 128,
	BarGap = 0,
} )

And, let's have instances groove to the beat:

Erika.new():Play( SOUND_ID_HERE ).OnBeat:Connect(function( Scale: number )
	UIScale.Scale = 1 + Scale * 0.5
end)

Tip

Methods are chainable, you can have it all!

Features

• One-line setup from SoundId to a playing, analyzable sound
• Built-in beat detection with Tangela.OnBeat, driven by Roblox's AudioAnalyzer
• Fully optional configuration with sensible defaults for everything
• Support for your own AudioPlayer & AudioAnalyzer instances

Setup

1. Insert the Erika library into any client-accessible service (e.g. ReplicatedStorage, StarterPlayerScripts)
2. Require Erika:
   • local Erika = require(<path to Erika>)
3. Read the API below to get started

API

Erika.new & Tangela:Set

local Tangela = Erika.new( string , {
	AudioPlayer = AUDIO_PLAYER_HERE,
	AudioAnalyzer = AUDIO_ANALYZER_HERE,
	WindowSize = Enum.AudioWindowSize[SIZE_HERE],
} )

Tangela:Set{
	SoundId = SOUND_ID_HERE,
	Looping = boolean,
	PlaybackSpeed = number,
	Volume = number,
}

Note

Erika is the class. Tangela is the object created by Erika.new.

Erika.new accepts optional constructor parameters that must be provided when creating the object. These parameters cannot be added after creation. Tangela:Set handles properties that can be configured or changed after the object has been created.

Warning

If you provide custom audio instances, provide both AudioPlayer and AudioAnalyzer together. Erika does not destroy user-provided instances.

Tangela:Destroy

Tangela:Destroy()

Stops beat detection, destroys every visualizer, disconnects subscriptions, and destroys only the AudioPlayer and AudioAnalyzer instances created internally. User-provided audio instances remain owned by the caller.

---

Tangela:Play

Tangela:Play{ SoundId = SOUND_ID_HERE , Looping = boolean , PlaybackSpeed = number , Volume = number }
Tangela:Play( SOUND_ID_HERE )

Plays the sound, overriding SoundId, Looping, or PlaybackSpeed if provided.

Note

Tangela:Play accepts either a table of options (same syntax as Tangela:Set) or just a SoundId directly.

Tangela:Stop

Tangela:Stop( boolean? )

Stops the sound. If the passed boolean is true, the sound will have its TimePosition reset to 0.

---

Tangela.Visualizers

for __ , Visualizer in Tangela.Visualizers do
	print( Visualizer )
end

Holds every visualizer created via Tangela:CreateVisualizer2D or Tangela:CreateVisualizer3D.

Caution

Modifying Visualizer directly is not recommended and may cause unexpected behavior. Proceed at your own discretion.

Tangela:CreateVisualizer2D

Tangela:CreateVisualizer2D( GuiObject , {
	BarCount = number,
	BarGap = number,
	BarDecay = number,
	BarMaxHeight = number,
	BarColorLow = Color3,
	BarColorHigh = Color3,
	MinHz = number,
	MaxHz = number,
} , ContainerAlignment , BarAlignment )

Creates a 2D bar visualizer parented to a GuiObject. All fields in the table are optional and fall back to sensible defaults.
ContainerAlignment and BarAlignment each accept Top, Bottom, or Center.

• BarCount: The number of bar frames created
• BarGap: The distance between every bar frame
• BarDecay: How long a bar frame holds its position before falling
• BarMaxHeight: The max scale a bar frame can reach
• BarColorLow: The color a bar frame is at its lowest
• BarColorHigh: The color a bar frame is at its highest
• MinHz: Locks the minimum accepted Hz
• MaxHz: Locks the maximum accepted Hz

Tangela:CreateVisualizer3D

Note

3D visualizers are planned but are not currently implemented.

Tangela:ClearVisualizers

Tangela:ClearVisualizers()

Destroys every visualizer created via Tangela:CreateVisualizer2D or Tangela:CreateVisualizer3D and empties Erika.Visualizers.

---

Tangela.OnBeat

Tangela.OnBeat:Connect(function( Scale: number )
	print( Scale )
end)

Fires every frame with a Scale value between 0 and 1, derived from the spectrum data given by the AudioAnalyzer.

Note

Multiple Tangela's may share the same AudioPlayer and AudioAnalyzer. Spectrum processing is shared internally, while each Tangela maintains its own beat subscription and beat preset.

Tangela:SetBeatPreset

Tangela:SetBeatPreset( 'Default' )

Remaps the values fired by Tangela.OnBeat. Built-in presets are:

• Default: input 0.0-1.0 → output 0.0-1.0
• Punchy: input 0.3–0.8 → output 0.8–1.0 (only strong hits register, and they hit hard)
• Subtle: input 0.2–0.9 → output 0.7–0.85 (a gentle pulse that never fully rests)
• Smooth: input 0.0–1.0 → output 0.1–0.6 (flattens peaks for continuous, non-jarring motion)
• Gate_Lw: binary on/off, switches to 1 once the beat crosses 50% intensity
• Gate_Av: binary on/off, switches to 1 once the beat crosses 70% intensity
• Gate_Hi: binary on/off, switches to 1 once the beat crosses 90% intensity

Credits

• Erika by Dani (danijayvv)
• Art by my lovely girlfriend, Anne
• Title Banner created with capsule-render
• Utilized Azul
